AT-XC
SHORT ACTION 6.5/6mm CREEDMOOR
COMPETITION RIFLE
Next generation Accuracy International low profile AT-XC rifles feature cross-platform design enhancements to match the demands of sporting communities worldwide and have successfully completed relevant NATO/military weapon tests for assurance of continued performance in the harshest conditions.
AT-XC CONFIGURATIONS
Includes long bridge with forend rail, folding hinge and bag rider
| CALIBER | BBL LENGTH | MUZZLE THREAD/PROTECTOR | MOUNTING SYSTEM |
|---|---|---|---|
| 6.5 Creedmoor | 24” 1:8 twist | 5/8” x 24 | KeySlot™ |
| 6mm Creedmoor | 26” 1:7.25 twist | 5/8” x 24 | KeySlot™ |
AT-XC FEATURES
List of Services
-
BUTT PADSHOW ME List Item 1
Toolless Quick adjust buttpad and length of pull: Min 321mm (12.6”) with a total range of 55mm (2.15”) in 5.5mm (0.215”) increments. Additional accessory butt spacers also available
-
CHEEKPIECESHOW ME List Item 2
Toolless quick adjust cheekpiece: Height range: 24.5mm (0.96” in 3.5mm (0.14”) increments. A hex key for barrel change etc.) is conveniently stored beneath
-
BAG RIDERItem Link List Item 3
Rail mounted adjustable bag rider.
-
FOLDING STOCKItem Link
The rigid and stable right folding chassis locks securely over the bolt. Reduces overall length by 8.86" (225 mm).
-
SLING POINTSItem Link
Three flush cup style points, two on rear end and one on side
-
PISTOL GRIPItem Link
ERGO replaceable pistol grip
-
SAFETYSHOW ME
Three position safety catch on the bolt shroud:
Locked (bolt cannot be lifted)
Safe (bolt can be lifted)
Fire (firing pin engaged)
-
TRIGGERItem Link
XTSP AI competition trigger. Two stage, set at 1.5 lbs.
Fore and aft adjustable and easily removed (two socket head screws) for cleaning
-
BOLTItem Link
Next generation with improved geometry, steel bolt body with maraging steel bolt head and lock ring, 6 lug, 60° bolt throw with AI leaf spring extractor and enlarged bolt knob.
List of Services
-
MAGAZINESHOW ME List Item 1
Detachable 10 round double stack magazine. Slim profile mag catch for ambidextrous removal.
-
ACTIONItem Link List Item 2
Next generation Proofed EN24T steel action with enhanced features, 20 MOA Mil Std 1913 action rail, overpressure ports, bolted to the aluminium chassis.
-
QUICKLOCItem Link List Item 3
AI’s patented system for barrel removal and refit including calibre/length change in minutes using the 4mm hex key stored under the cheekpiece.
-
TRIPOD INTERFACEItem Link List Item 4
The flat bottomed forend features an integral RRS (Arca-Swiss style) interface for bipods or tripods.
-
BARRIER SUPPORTItem Link
The lower chassis front face is machined to provide a rugged barricade support
-
FULL LENGTH BRIDGEItem Link
Low profile single plane forend 397mm (15.63”) to fit barrels with a minimum length of 508mm (20”) and maximum diameter of 31mm (1.22”) with full length bridge and 20 MOA co-planar rail.
-
BARRELSItem Link
Stainless Steel cut-rifled competition match grade barrels with M27 barrel tenon and 5/8x24 muzzle threads, manufactured in the USA.
-
MUZZLE PROTECTORItem Link
Securely protects the 5/8 x24 muzzle thread when barrel not connected to a suppressor or muzzle brake
-
CHASSISItem Link
7075 aluminium chassis with superior AI KeySlot™ mounting system. Right side folding stock over the bolt.
AT-XC COLORS
RED
BLACK
SAGE GREEN
DARK EARTH
AT-XC SPECIFICATION
CALIBERS
6.5 Creedmoor
6 mm Creedmoor
WEIGHT
6.5 CM with hinge, bridge with full length rail, bag rider, empty magazine, no scope, 24” barrel, no muzzle brake, no bipod: 13.1 lb
DIMENSIONS
With 24” barrel
Full length: 45.6”
Stock folded: 36.8”
BARRELs
6.5 CM: 24” bbl, 1 in 8 twist
6 mm CM: 26” bbl, 1 in 7.25 twist
GENERAL SPECIFICATION
• Next generation Proofed EN24T steel action and bolt body with maraging steel bolt head and lock ring bolted to the aluminum chassis
• 20 MOA Mil Std 1913 action rail and forend rail for use with in-line night vision or thermal scopes
• 6 lug, with improved geometry, 60° bolt throw with AI leaf spring extractor and enlarged bolt knob
• 3 position safety
• AI/XTSP two-stage trigger set at 1.5 lbs
• Quickloc barrel change system: remove/refit barrels in minutes using 4mm hex key
• Overpressure ports
• Stainless steel match grade barrels with M27 barrel tenon and 5/8 x 24 muzzle thread
• Aluminum chassis with RRS spec / Arca-Swiss style interface and barricade support. Left side port cut out for ease of magazine insertion
• KeySlot™ forend mounting system
• Right side folding stock over bolt
• Toolless quick adjust cheekpiece, buttpad
and LOP
• Detachable 10 round double stack magazine
• Adjustable bag rider
• Flush cup sling attachment points
• User manual
AT-XC SNAPSHOTS
Click for a bigger pic...
AT-XC DOWNLOADS
AT-XC
SHORT ACTION 6.5 / 6mm CREEDMOOR
COMPETITION RIFLE
