AXSR LE
LONG ACTION MULTI CAL
LAW ENFORCEMENT
The next generation Accuracy International high performance, AXSR-LE rifle features cross-platform enhancements to match the rigorous demands of law enforcement professionals.
AXSR LE CONFIGURATIONS
| CALIBER | BBL LENGTH | MUZZLE THREAD & PROTECTOR | MOUNTING SYSTEM |
|---|---|---|---|
| .338LM | 20" 1:9.35 twist | 3/4 x 24" | KeySlot™ |
| .338LM | 27" 1:9.35 twist | 3/4 x 24" | KeySlot™ |
.308 CALIBER CONVERSION to include a complete bolt assembly, magazine and barrel
AXSR LE FEATURES
List of Services
-
BUTT PADSHOW ME List Item 1
Toolless, quick adjust butt pad with spacers, and LOP
-
CHEEKPIECESHOW ME List Item 2
Height adjustable to allow for night vision equipment or telescopic sights with large objective lenses. A hex key for barrel change etc. is convenientLy stored underneath.
-
BAG RIDERItem Link List Item 3
Rail mounted adjustable bag rider
-
FOLDING STOCKSHOW ME List Item 4
The rigid and stable right folding chassis locks securely over the bolt. Reduces overall length
-
SLING POINTSItem Link
Five flush cup style attachment points, two on rear end, one on side, and two repositional on the forend tube
-
PISTOL GRIPItem Link
Rubber AR style replaceable pistol grip
-
SAFETYSHOW ME
Three position safety catch
Locked (bolt cannot be lifted)
Safe (bolt can be lifted)
Fire (firing pin engaged)
-
TRIGGERItem Link
Standard two stage AI trigger set at 4 lbs. Easily removed for cleaning
-
BOLTItem Link
Steel bolt body with maraging steel bolt head and lock ring, 6 lug, 60° bolt and AI combat proven leaf spring extractor
List of Services
-
MAGAZINESHOW ME List Item 1
Detachable 10 round double stack magazine. Slim profile mag catch for ambidextrous removal. Cut out magazine port on the left side for ease of insertion
-
ACTIONItem Link List Item 2
Next generation Proofed EN24T steel action. 20 MOA Mil Std 1913 action rail and forend rail. Overpressure ports
-
QUICKLOCItem Link List Item 3
AI’s patented system for barrel removal and refit including calibre/length change in minutes using the 4mm hex key stored under the cheekpiece
-
BARRICADE SUPPORTItem Link
Aluminum chassis with RRS spec / Arca-Swiss style interface and barricade support
-
FORENDItem Link
16" Free floating forend tube with integrated RRS rail along bottom. KeySlot™ mounting system for accessory rails
-
BARRELSItem Link
Stainless Steel match grade barrels with M30 barrel tenon and 3/4 x 24" muzzle thread. Manufactured in the USA
-
MUZZLE PROTECTORItem Link
Securely protects the muzzle thread when barrel not connected to a suppressor or muzzle brake
-
.308 CALIBER KITItem Link
.308 caliber conversion kit includes a
complete bolt assembly, magazine
and barrel
AXSR LE ACCESSORIES
AXSR LE COLORS
SNIPER GREY
SAGE GREEN
DARK EARTH
AXSR LE SPECIFICATION
CALIBERs
.338LM
.308 caliber conversion to include a complete bolt assembly, magazine and barrel
BARREL OPTIONS
.338LM 20”bbl, 1 in 9.35 twist, ¾ x 24” with thread protector (no muzzle brake)
.338LM 27”bbl, 1 in 9.35 twist, ¾ x 24” with thread protector (no muzzle brake)
GENERAL SPECIFICATION
• Next generation Proofed EN24T steel action and bolt body with maraging steel bolt head and lock ring bolted to the aluminum chassis
• 20 MOA Mil Std 1913 action rail and forend rail for use with in-line night vision or thermal scopes
• 6 lug with improved geometry, 60° bolt throw with AI leaf spring extractor
• 3 position safety
• AI Standard Two-stage trigger set at 4 lbs
• Quickloc barrel change system: remove/refit barrels in minutes using 4mm hex key
• Overpressure ports
• Stainless steel match grade barrels with M30 barrel tenon and ¾ x 24" muzzle thread
• Aluminum chassis with RRS spec/Arca-Swiss style interface and barricade support. Left side port cut out for ease of magazine insertion
• 16” Forend tube with integrated RRS rail along bottom
• KeySlot™ forend mounting system complete
with 1 x 3.15” flush cup rail, 1 x 3.15” and 1 x 5.5” plain accessory rails
• Right side folding stock over bolt
• Toolless quick adjust cheekpiece, buttpad
and LOP
• Detachable 10 round double stack magazine
• Designed to accept most AR style grips
• Adjustable bag rider
• Flush cup sling attachment points
• User manual
• Left-hand option
